Mills dance master amp
by Hans Minderman 10 Apr '26

10 Apr '26

Hi All, I’m finishing up a Mills Dance Master, I have it all mechanically working and I’m now ready to work on the amp (an MCP 1644 amp). I have a schematic for it from the manual but it is not very useful because the caps and resistors are only marked with the mills ‘mcp’ catalog number and not with the actual values. The corresponding parts list has the same issue with just listing the Mills catalog numbers and not actual values. I checked with Bill Bickers at Jukebox friday night but he does not have a schematic with values or a rebuilt kit either. If anyone has a schematic or a listing of the caps and the resistors and choke for this amp please let me know. Thank you for your help. Hans Sent from Mail<https://go.microsoft.com/fwlink/?LinkId=550986> for Windows

4 3

Updated Wurlitzer Service Slants and Kit documents
by John Robertson 02 Feb '25

02 Feb '25

Happy New Year! I've spent a few more hours updating the web page! These are very handy to the Wurlitzer technician and worth looking at and downloading. I watermark them with flippers.com as I don't want people selling them, they should be free as long as I have any say in the matter... www.flippers.com Wurlitzer USA Service Bulletins and more! <#> 🔗 https://www.flippers.com/Wurl_USA.html <https://www.flippers.com/Wurl_USA.html> Please feel free to send me anything you have to fill my holes in the list! Thanks, John :-#)# -- John's Jukes Ltd. 7 - 3979 Marine Way, Burnaby, BC, Canada V5J 5E3 Call (604)872-5757 (Pinballs, Jukes, Video Games) flippers.com "Old pinballers never die, they just flip out"

2 2

Seeburg Symphonola 1940
by Tony Miklos 13 Dec '24

13 Dec '24

I've never looked at the insides of one of these, all I know is that it doesn't play. And of course "It all lights up and everything" :) Anyway, from what I could see in the poor pics of the mech, it looks fairly simple. Are they easy? Trying to decide if I want to take the job or not since I have an open spot in the shop. Tony

5 14

About to prank my sister.
by Jay Hennigan 01 Dec '24

01 Dec '24

She shows up every Thanksgiving and selects her favorite song on the jukebox just when everyone sits down to eat. This year will be different. See linked image. https://jayh1.imgbb.com/ -- Jay Hennigan - jay(a)west.net Network Engineering - CCIE #7880 503 897-8550 - WB6RDV

2 1

Happy Thanksgiving
by Tony Miklos 01 Dec '24

01 Dec '24

I wish each and every one (in the US) a happy Thanksgiving! And to those in other countries I wish a happy day! Tony

4 3

Seeburg 161
by Donald Whiting 29 Nov '24

29 Nov '24

Hi all I could use some guidance… I’m working on my Seeburg 161 I purchased. It has a HFMA2 amp that was rebuilt by the previous owner . I have two issues first is…as a record begins to play there is no hum however as the AVC kicks in the hum begins and increases and is quite loud then gets drowned out by the music until the end of the song where it is very loud until the mute switch kicks in. Any thought? Second issue is the mech sometimes “jitters” or starts and stops rapidly after record play it will eventually begin to scan properly. Any guidance is appreciated… Don

4 12

Happy National Jukebox Day!
by Shankar Singh 27 Nov '24

27 Nov '24

Some links on the subject below. Enjoy! Shankar Singh https://nationaltoday.com/national-jukebox-day/ https://www.the-star.co.ke/news/realtime/2024-11-27-national-jukebox-day-ho… https://www.nationaldaycalendar.com/national-day/national-jukebox-day-day-b…

2 1

Rockola CD8B power issue
by Jukebox Repairman 20 Nov '24

20 Nov '24

Customer contacted me about his CD juke. States he hadn’t played it for awhile and when he made a selection, it loaded the disc, started to spin then machine went completely dark. I asked him to look at LED’s on power supply and he told me the only one lighted is the 24VDC I went there yesterday and checked all fuses in the supply and the amp. All good. Nothing looks burnt on the board. Does this sound like a transformer fried???

3 7

HFMA1 amplifier R48 Value
by M De Simone 19 Nov '24

19 Nov '24

Hey there esteemed members, seems like I’m on a run with questions lately. I need to replace the 25k section of the dual value 20watt “standee” resistor in this amplifier from a Seeburg V200. My question: is each section 20watts or is it 10watts per section, for a total of 20watts? Reason I ask is that I have, on hand, 2- 5w resistors I can put in series and I’d be done but if I need a 20 watt then I have start hunting one down. Parts list/manual doesn’t help here. Thanks, Mauro Sent from my iPhone

3 7

AMI WQ200 bench test
by M De Simone 18 Nov '24

18 Nov '24

Hello All, Can anyone tell me if I can test an AMI WQ200 wallbox on the bench with just powering the 26vac? I have one that will select if I help turn the motor a bit but coins do not advance the wiper blades. I’ve made some adjustments and did some contact cleaning but it does the same thing. I’m wondering if I need a DC voltage or something else? Thank you for any advice, Mauro Sent from my iPhone

5 9
